1. Product Overview

The Beidou Ecological Environment Monitoring Station FZ6 is an automated meteorological monitoring device independently developed by our company, combining Beidou Navigation Satellite System's regional short message communication technology and meteorological environment monitoring technology. The system equipment has the characteristics of autonomous operation, real-time transmission, intelligent monitoring, and accurate forecasting. It can monitor the meteorological environment changes 24 hours a day without interruption, greatly solving the environmental monitoring problems in areas without signals or weak signals. At present, the Beidou automatic meteorological station has been widely used in various places in China, providing important support for weather forecasting and environmental early warning.
     Compared with traditional ultrasonic meteorological stations, our company's products overcome the need for high-precision timing devices, avoid the problems of inaccurate measurement caused by sensor startup delay, modulation circuit delay, and temperature changes. The equipment innovatively uses an eight-element integrated sensor, which can observe ultrasonic wind speed and direction, temperature, humidity, atmospheric pressure, optical rain gauge, total radiation, negative oxygen ions, and other meteorological elements in real-time, and can achieve 24-hour continuous online monitoring of outdoor meteorological parameters. Through the digital communication interface, the eight parameters are output to the user at one time.

Second, product features

1. Top cover hidden ultrasonic probe to avoid interference from rain and snow accumulation, and to prevent natural wind from blocking ☆
2. The principle is to emit continuous variable frequency ultrasonic signals, and to detect wind speed and direction by measuring the relative phase ☆
3. An integrated sensor for wind speed, wind direction, temperature, humidity, atmospheric pressure, optical rain gauge, total radiation, and negative oxygen ions ☆
4. Two-meter carbon steel bracket, no flange required at the top, can directly fit the sensor
5. The sensor housing is made of imported ASA material, more effectively against salt spray and other environments, with a protection grade of IP65 or above

Three, Technical parameters

1. Wind Speed: Measurement principle is ultrasonic, 0～60m/s (±0.1m/s + 0.01V), Resolution 0.01m/s;
2. Wind Direction: Measurement principle is ultrasonic, 0～360° (±2°); Resolution: 1°;
3. Air Temperature: Measurement principle is the junction voltage method of a diode, -40-80℃ (±0.3℃ (25℃)), Resolution 0.01℃;
4. Air Humidity: Measurement principle is capacitive, 0-100% RH (±3% RH (20%~80%)), Resolution: 0.01% RH;
5. Atmospheric Pressure: Measurement principle is piezoresistive, 300-1100Hpa (±0.25%), Resolution 0.1hpa;
6. Optical Rain Gauge: Measurement principle is photoelectric, 0-4mm/min (≤±4%), Resolution 0.01mm;
7. Global Radiation: Measurement principle is the photoelectric effect, 0~1242W/㎡ (＜±3%), Resolution 1W/㎡
8. Negative Oxygen Ions: Measurement principle: cylindrical electrode suction type; 0～100,000/cm3, Resolution 1/cm3; Measurement error:  Reading ±10%; ion migration rate ≤ ±20%; Measurement resolution: 1/cm3;
9. Beidou Data Transmission Terminal: Power supply:RegulatedVoltageSourceDC12, current 3A power: transmission power 36W, standby power 1w
10. Standard Beidou Card: Transmission capacity 260 bytes, message service 1 year

11. RDSS indicators: communication success rate 95%
12. Transmission frequencies Lf0, Lf1, Lf2.

13. Information transmission mode: Chinese characters, codes, mixed compilation
14. Installation angle: The antenna is vertical and facing up, with no obstructions directly above the antenna, avoid installing in places with strong magnetic signal interference, such as high-voltage towers, large-power base stations, etc.
15. External data interface: RS485、RS232
16. Reliability: Working temperature -20℃～+70℃, storage temperature -40℃～+85℃, protection capability IP67
Acquisition unit power interface: GX-12-4P, input voltage regulated DC12V, with RS485 output json data format;
17. Sensor modbus-RTU protocol, GX-12-4P plug 485 interface, output supply voltage 12V/1-3A, device configuration interface: GX-12-4P plug, input voltage 12V
18. Solar power supply 100WSolar panel100AHGlutaraldehyde battery, Charging controller: 150W

19. Data upload interval: 2 minutes - 1000 minutes adjustable
20. Android 7-inch touch screen, screen resolution: 1024*600 RGB LCD (optional)
21. The manufacturer has ISO quality management system, environmental management system and occupational health management system certification
22. The manufacturer has a computer software registration certificate
23. The manufacturer is a 3A credit enterprise
